4' Hazardous Location Fluorescent Vapor Tight, 2 and 3 Lamps, IP67, NSF, NEMA 4X, CLASS I, DIVISION II
4' Hazardous Location Fluorescent Vapor Tight, 2 and 3 Lamps, IP67, NSF, NEMA 4X, CLASS I, DIVISION II

4' Hazardous Location Fluorescent Vapor Tight, 2 and 3 Lamps, IP67, NSF, NEMA 4X, CLASS I, DIVISION II

  • SKU : VX4
  • Model No :
  • Availablity : in Stock
  • Categories : Hazardous Location

The VX4 is our IP67, NSF gasketed 4 foot linear luminaire designed for use in hazardous locations when gases and liquids may be present. Acetylene, hydrogen, ether, hydrocarbons, fuels, solvents etc. that are not normally present in an explosive concentration (but may accidently exist). Housing:  The housing is constructed from a one piece reinforced fiberglass, a closed cell, high temperature poured in place gasket and polycarbonate latches seal the enclosure from most hostile environments. Mounting: Ceiling mounting brackets and mounting bail brackets for suspended mount included.

Login to view price
Certificates & Certifications
Certificate 1
Certificate 2
Certificate 3
Certificate 4
Certificate 5
Certificate 6
Specifications
Application Industrial, Commercial, Hazardous
Mounting Surface, Suspended
Lamp Type / Light Source Fluorescent T5, Fluorescent T8, Fluorescent T5HO
Size 48"
Number of Lamps 2, 3
Material Fiberglass
Casting/Housing Color White
Wattage 54 W, 28 W, 32 W
Voltage 120 V, 120-277 V, 347 V
Ratings Class I Division 2, Class III Division 1 & 2, NSF, NEMA 4X, IP67
Environment Wet, Hazardous
Product Type Vapor Tight
